Provides brief, high-level overviews of the architectures and applications of Fiber-to-the-Home (FTTH) or Fiber-to-the-Curb (FTTC) access networks and the alternative HFC, subscriber line, and WiMAX acces
Table of Contents
Preface xi 1 PON in the Access Picture 1
1.1 Why Passive Optical Network (PON) for the Last Mile Access?, 1
1.2 Services and Applications, 4
1.2.1 Displacement of Legacy High-Speed Access Services, 4
1.2.2 Internet Protocol (IP) over PON, 6
1.2.3 Triple Play and Quadruple Play, 6
1.2.4 Multimedia Conferencing and Shared Environments, 8
1.2.5 Backhaul Services, 8
1.2.6 Cloud-Based Services, 10
1.3 Legacy Access Technologies, 10
1.3.1 Hybrid Fiber-Coax (HFC) Cable Data System, 10
1.3.2 Digital Subscriber Line (DSL), 13
1.3.3 Broadband over Powerline (BoPL), 15
1.3.4 Broadband Wireless Access (BWA), 16
1.4 Fiber-Optic Access Systems, 18
1.4.1 PON as a Preferred Optical Access Network, 20
1.5 PON Deployment and Evolution, 22
References, 24
2 PON Architecture and Components 27
2.1 Architectural Concepts and Alternatives, 27
2.1.1 Topologies, 27
2.1.2 Downstream and Upstream Requirements, 30
2.1.3 BPON, GPON, and EPON Systems, 30
2.1.4 Medium Access Techniques, 34
2.2 Passive and Active PON Components, 37
2.2.1 Passive Optical Coupler, 37
2.2.2 Splitter, 38
2.2.3 Arrayed Waveguide Grating (AWG), 40
2.2.4 Optical Line Termination (OLT), 41
2.2.5 ONU/ONT, 41
2.3 Management and Control Elements, 43
2.3.1 Bandwidth Allocation, 43
2.3.2 Quality of Service (QoS), 44
2.3.3 Deployment and Maintenance, 46
2.3.4 Problems and Troubleshooting, 47
References, 50
3 Techniques and Standards 53
3.1 BPON Overview, 55
3.1.1 Basic Asynchronous Transfer Mode (ATM) Concepts, 56
3.2 The Full Service Access Network (FSAN) (ITU-T G.983) BPON Standard, 58
3.2.1 Downstream Transmission, 62
3.2.2 Upstream Transmission, 64
3.2.3 Management Functions, 65
3.2.4 Wavelength Division Multiplexing (WDM), 65
3.2.5 Dynamic Bandwidth Allocation (DBA), 67
3.2.6 Protection Switching, 67
3.3 GPON, 68
3.3.1 GPON Encapsulation Method (GEM), 69
3.3.2 Downstream Transmission, 70
3.3.3 Upstream Transmission, 72
3.3.4 Ranging, 73
3.3.5 Security, 74
3.4 EPON, 74
3.4.1 EPON Switched Ethernet, 77
3.4.2 1000BASE-PX10, 1000BASE-PX20, and 10G EPON PMD Types, 78
3.4.3 Medium Access Control (MAC), 79
3.4.4 Comparison of 1G EPON and GPON, 83
3.4.5 Service Interoperability in EPON (SIEPON), 85
References, 86
4 Recent Advances and Looking to the Future 87
4.1 Interoperability, 87
4.1.1 Implementing 1:1 and 1:N Interoperability Testing, 89
4.1.2 Management and Quality-of-Service (QoS) Challenges, 91
4.2 Wavelength Division Multiplexed PON (WDM-PON), 91
4.2.1 Coarse Wavelength Division Multiplexing (CWDM)-PON and Dense Wavelength Division Multiplexing (DWDM)-PON, 93
4.2.2 WDM Devices, 95
4.3 Subcarrier PON, 97
4.4 Long-Reach PON, 100
4.5 Optical–Wireless Integration, 100
4.5.1 Architecture, 101
4.5.2 Integration Modes, Benefits, and Challenges, 103
4.5.3 Support of Next-Generation Cellular Mobile, 106
4.5.4 The Future of Optical–Wireless Integration, 107
4.6 Scaling Up PON to Much Higher Transmission Rates, 108
4.7 Conclusion, 111
References, 111
Appendix: Excerpts from the IEEE 10 Gbps EPON Standard 802.3av-2009 115
Index 183
