Description
Book Synopsis*
Trade Review"Provides a thorough presentation of the state-of-the art in computational modelling techniques for photonics Contains broad coverage of both frequency- and time-domain techniques to suit a wide range of photonic devices Reviews existing commercial software packages for photonics". (MyCFO, 20 January 2011)
"In this book, the author provides a comprehensive coverage of modern numerical modelling techniques for designing photonic devices for use in modern optical telecommunication". (VentureBeat Profiles, 21 January 2011)
Table of Contents1 Introduction 1.1 Photonics: the countless possibilities of light propagation
1.2 Modelling photonics
2 Full-vectorial Beam Propagation Method
2.1 Introduction
2.2 Overview of the beam propagation methods
2.3 Maxwell’s Equations
2.4 Magnetic field formulation of the wave equation
2.5 Electric field formulation of the wave equation
2.6 Perfectly-Matched Layer
2.7 Finite Element Analysis
2.8 Derivation of BPM Equations
2.9 Imaginary-Distance BPM: Mode Solver
3 Assessment of Full-Vectorial Beam Propagation Method
3.1 Introduction
3.2 Analysis of Rectangular waveguide
3.3 Photonic Crystal Fibre
3.4 Liquid Crystal Based Photonic Crystal Fibre
3.5 Electro-optical Modulators
3.6 Switches
4 Bidirectional Beam Propagation Method
4.1 Introduction
4.2 Optical Waveguide Discontinuity Problem
4.3 Finite element analysis of discontinuity problems
4.4 Derivation of Finite Element Matrices
4.5 Application of Taylor’s Series Expansion
4.6 Computation of Reflected, Transmitted and Radiation Waves
4.7 Optical fiber-facet problem
4.8 Finite element analysis of optical fiber facets
4.9 Iterative analysis of multiple-discontinuities
4.10 Numerical assessment
5 Complex-Envelope Alternating-Direction-Implicit Finite Difference Time Domain Method with Assessment
5.1 Introduction
5.2 Maxwell's equations
5.3 Brief history of Finite Difference Time Domain (FDTD) Method
5.4 Finite Difference Time Domain (FDTD) Method
5.5 -Direction-Implicit FDTD (ADI-FDTD): Beyond the Courant Limit
5.6 Complex-Envelope ADI-FDTD (CE-ADI-
5.7 Perfectly Matched Layer (PML) Boundary Conditions
5.8 Uniaxal Perfectly Matched Layer (UPML) Absorbing Boundary Condition
5.9 PML Parameters
5.10 PML Boundary Conditions for CE-ADI-FDTD
5.11 PhC Resonant Cavities
5.12 5x5 Rectangular Lattice PhC Cavity
5.13 Triangular Lattice PhC Cavity
5.14 Wavelength Division Multiplexing
5.15 Conclusions
6. Finite Volume time Domain (FVTD) Method
6.1 Introduction
6.2 Numerical analysis
6.3 UPWIND Scheme for the Calculation
6.4 NON-DIFFUSIVE Scheme for the Flux Calculation
6.5 2D Formulation of the FVTD Method
6.6 Boundary Conditions
6.7 Nonlinear Optics
6.8 Nonlinear Optical Interactions
6.9 Extension of the FDTD Method to Nonlinear Problems
6.10 Extension of the FVTD Method to Nonlinear Problems
6.11 Conclusions
7 Numerical Analysis of Linear and Nonlinear PhC Based Devices
7.1 Introduction
7.2 FVTD Method Assessment: PhC Cavity
7.3 FVTD Method Assessment: PhC Waveguide
7.4 FVTD Method Assessment: PBG T-Branch
7.5 PhC Multimode Resonant Cavity
7.6 FDTD Analysis of Nonlinear Devices
7.7 FVTD Analysis of Nonlinear Photonic Crystal Wires
7.8 Conclusions
8 Multiresolution Time Domain
8.1 Introduction
8.2 MRTD basics
8.3 MRTD update scheme
8.4 Scaling-MRTD
8.5 Conclusions
9 MRTD Analysis of PhC-Devices
9.1 Introduction
9.2 UPML-MRTD: test and code validation
9.3 MRTD vs FDTD for the analysis of linear photonic crystals
9.4 Conclusions
10 MRTD Analysis of SHG PhC-Devices
10.1 Introduction
10.2 Second harmonic generation in optics
10.3 Extended S-MRTD for SHG analysis
10.4 SHG in PhC-waveguide
10.5 Selective SHG in compound PhC-based structures
10.6 New design for selective SHG: PhC-microcavities coupling
10.7 Conclusions
11 Dispersive Nonlinear MRTD for SHG Applications
11.1 Introduction
11.2 Dispersion analysis
11.3 SHG-MRTD scheme for dispersive materials
11.4 Simulation results
11.5 Conclusions
