Description
Book SynopsisMaintenance and continuous health monitoring of air, land and sea structures is one of the most important concerns in a wide range of industries including transportation and civil engineering. Effective maintenance minimises not only the cost of ownership of structures but also improves safety and the perception of safety.
Trade Review"...very relevant and timely...strongly recommend this multidisciplinary book...an integrated volume of real value..." (Measurement and Control, Vol 37(5), June 2004)
Table of ContentsList of Contributors. Preface.
1. Introduction (G. Bartelds, J.H. Heida, J. McFeat and C. Boller).
1.1 Health and Usage Monitoring in Aircraft Structures – Why and How?
1.2 Smart Solution in Aircraft Monitoring.
1.3 End-User Requirements.
1.3.1 Damage Detection.
1.3.2 Load History Monitoring.
1.4 Assessment of Monitoring Technologies.
1.5 Background of Technology Qualification Process.
1.6 Technology Qualification.
1.6.1 Philosophy.
1.6.2 Performance and Operating Requirements.
1.6.3 Qualification Evidence – Requirements and Provision.
1.6.4 Risks.
1.7 Flight Vehicle Certification.
1.8 Summary.
References.
2. Aircraft Structural Health and Usage Monitoring (C. Boller and W.J. Staszewski).
2.1 Introduction.
2.2 Aircraft Structural Damage.
2.3 Ageing Aircraft Problem.
2.4 LifeCycle Cost of Aerospace Structures.
2.4.1 Background.
2.4.2 Example.
2.5 Aircraft Structural Design.
2.5.1 Background.
2.5.2 Aircraft Design Process.
2.6 Damage Monitoring Systems in Aircraft.
2.6.1 Loads Monitoring.
2.6.2 Fatigue Monitoring.
2.6.3 Load Models.
2.6.4 Disadvantages of Current Loads Monitoring Systems.
2.6.5 Damage Monitoring and Inspections.
2.7 Non-Destructive Testing.
2.7.1 Visual Inspection.
2.7.2 Ultrasonic Inspection.
2.7.3 Eddy Current.
2.7.4 Acoustic Emission.
2.7.5 Radiography, Thermography and Shearography.
2.7.6 Summary.
2.8 Structural Health Monitoring.
2.8.1 Vibration and Modal Analysis.
2.8.2 Impact Damage Detection.
2.9 Emerging Monitoring Techniques and Sensor Technologies.
2.9.1 Smart Structures and Materials.
2.9.2 Damage Detection Techniques.
2.9.3 Sensor Technologies.
2.9.4 Intelligent Signal Processing.
2.10 Conclusions.
References.
3. Operational Load Monitoring Using Optical Fibre Sensors (P. Foote, M. Breidne, K. Levin, P. Papadopolous, I. Read, M. Signorazzi, L.K. Nilsson, R. Stubbe and A. Claesson).
3.1 Introduction.
3.2 Fibre Optics.
3.2.1 Optical Fibres.
3.2.2 Optical Fibre Sensors.
3.2.3 Fibre Bragg Grating Sensors.
3.3 Sensor Target Specifications.
3.4 Reliability of Fibre Bragg Grating Sensors.
3.4.1 Fibre Strength Degradation.
3.4.2 Grating Decay.
3.4.3 Summary.
3.5 Fibre Coating Technology.
3.5.1 Polyimide Chemistry and Processing.
3.5.2 Polyimide Adhesion to Silica.
3.5.3 Silane Adhesion Promoters.
3.5.4 Experimental Example.
3.5.5 Summary.
3.6 Example of Surface Mounted Operational Load Monitoring Sensor System.
3.6.1 Sensors.
3.6.2 Optical Signal Processor.
3.6.3 Optical Interconnections.
3.7 Optical Fibre Strain Rosette.
3.8 Example of Embedded Optical Impact Detection System.
3.9 Summary.
References.
4. Damage Detection Using Stress and Ultrasonic Waves (W.J. Staszewski, C. Boller, S. Grondel, C. Biemans, E. O’Brien, C. Delebarre and G.R. Tomlinson).
4.1 Introduction.
4.2 Acoustic Emission.
4.2.1 Background.
4.2.2 Transducers.
4.2.3 Signal Processing.
4.2.4 Testing and Calibration.
4.3 Ultrasonics.
4.3.1 Background.
4.3.2 Inspection Modes.
4.3.3 Transducers.
4.3.4 Display Modes.
4.4 Acousto-Ultrasonics.
4.5 Guided Wave Ultrasonics.
4.5.1 Background.
4.5.2 Guided Waves.
4.5.3 Lamb Waves.
4.5.4 Monitoring Strategy.
4.6 Piezoelectric Transducers.
4.6.1 Piezoelectricity and Piezoelectric Materials.
4.6.2 Constitutive Equations.
4.6.3 Properties.
4.7 Passive Damage Detection Examples.
4.7.1 Crack Monitoring Using Acoustic Emission.
4.7.2 Impact Damage Detection in Composite Materials.
4.8 Active Damage Detection Examples.
4.8.1 Crack Monitoring in Metallic Structures Using Broadband Acousto-Ultrasonics.
4.8.2 Impact Damage Detection in Composite Structures Using Lamb Waves.
4.9 Summary.
References.
5. Signal Processing for Damage Detection (W.J. Staszewski and K. Worden).
5.1 Introduction.
5.2 Data Pre-Processing.
5.2.1 Signal Smoothing.
5.2.2 Signal Smoothing Filters.
5.3 Signal Features for Damage Identification.
5.3.1 Feature Extraction.
5.3.2 Feature Selection.
5.4 Time–Domain Analysis.
5.5 Spectral Analysis.
5.6 Instantaneous Phase and Frequency.
5.7 Time–Frequency Analysis.
5.8 Wavelet Analysis.
5.8.1 Continuous Wavelet Transform.
5.8.2 Discrete Wavelet Transform.
5.9 Dimensionality Reduction Using Linear and Nonlinear Transformation.
5.9.1 Principal Component Analysis.
5.9.2 Sammon Mapping.
5.10 Data Compression Using Wavelets.
5.11 Wavelet-Based Denoising.
5.12 Pattern Recognition for Damage Identification.
5.13 Artificial Neural Networks.
5.13.1 Parallel Processing Paradigm.
5.13.2 The Artificial Neuron.
5.13.3 Multi-Layer Networks.
5.13.4 Multi-Layer Perceptron Neural Networks and Others.
5.13.5 Applications.
5.14 Impact Detection in Structures Using Pattern Recognition.
5.14.1 Detection of Impact Positions.
5.14.2 Detection of Impact Energy.
5.15 Data Fusion.
5.16 Optimised Sensor Distributions.
5.16.1 Informativeness of Sensors.
5.16.2 Optimal Sensor Location.
5.17 Sensor Validation.
5.18 Conclusions.
References.
6. Structural Health Monitoring Evaluation Tests (P.A. Lloyd, R. Pressland, J. McFeat, I. Read, P. Foote, J.P. Dupuis, E. O’Brien, L. Reithler, S. Grondel, C. Delebarre, K. Levin, C. Boller, C. Biemans and W.J. Staszewski).
6.1 Introduction.
6.2 Large-Scale Metallic Evaluator.
6.2.1 Lamb Wave Results from Riveted Metallic Specimens.
6.2.2 Acoustic Emission Results from a Full-Scale Fatigue Test.
6.3 Large-Scale Composite Evaluator.
6.3.1 Test Article.
6.3.2 Sensor and Specimen Integration.
6.3.3 Impact Tests.
6.3.4 Damage Detection Results – Distributed Optical Fibre Sensors.
6.3.5 Damage Detection Results – Bragg Grating Sensors.
6.3.6 Lamb Wave Damage Detection System.
6.4 Flight Tests.
6.4.1 Flying Test-Bed.
6.4.2 Acoustic Emission Optical Damage Detection System.
6.4.3 Bragg Grating Optical Load Measurement System.
6.4.4 Fibre Optic Load Measurement Rosette System.
6.5 Summary.
References.
Index.
