Description
Book SynopsisYour guide to the design and construction of foundations on expansive soils Foundation Engineering for Expansive Soils fills a significant gap in the current literature by presenting coverage of the design and construction of foundations for expansive soils.
Table of ContentsPreface xv
List of Symbols xix
List of Abbreviations xxv
1. INTRODUCTION 1
1.1 Purpose 2
1.2 Organization 2
1.3 Terminology 4
References 7
2. NATURE OF EXPANSIVE SOILS 9
2.1 Microscale Aspects of Expansive Soil Behavior 9
2.1.1 The Clay Particle 10
2.1.2 Adsorbed Cations and Cation Hydration 15
2.1.3 The Clay Micelle 17
2.1.4 Crystalline and Osmotic Expansion 19
2.1.5 Effect of Mineralogy on Plasticity of Soil 21
2.1.6 Effect of Mineralogy on Expansion Potential 22
2.1.7 Effect of Type of Cation on Expansion Potential 22
2.2 Macroscale Aspects of Expansive Soil Behavior 24
2.2.1 Development of Natural Soil Deposits 24
2.2.2 Effect of Plasticity on Expansion Potential 26
2.2.3 Effect of Soil Structure, Water Content, and Density on Expansion Potential 27
2.3 Identification of Expansive Soils 30
2.3.1 Methods Based on Physical Properties 30
2.3.2 Mineralogical Methods 36
2.3.3 Chemical Methods 37
2.3.4 Comments on Identification Methods 39
2.4 Characteristics of Expansive Soil Profiles 40
2.4.1 Geographic Distribution of Expansive Soils 40
2.4.2 Expansive Soil Profiles 40
References 53
3. SITE INVESTIGATION 59
3.1 Program of Exploration 59
3.1.1 Reconnaissance Investigation 60
3.1.2 Preliminary Investigation 60
3.1.3 Design-Level Investigation 61
3.2 Forensic Investigation 68
References 72
4. SOIL SUCTION 74
4.1 Soil Suction Components 74
4.1.1 Matric Suction 76
4.1.2 Osmotic Suction 80
4.1.3 Total Suction 82
4.2 Soil Water Characteristic Curve 82
4.2.1 Mathematical Expressions for SWCC 84
4.2.2 Soil Water Characteristic Curves for Expansive Soils 86
4.2.3 Influence of Stress State on Soil Water Characteristic Relationships 89
4.2.4 Effect of Suction on Groundwater Profiles 89
4.3 Measurement of Matric Suction 90
4.3.1 Tensiometers 92
4.3.2 Axis Translation Technique 94
4.3.3 Filter Paper Method for Matric Suction 98
4.3.4 Thermal Conductivity Sensors 103
4.3.5 Electrical Resistance Sensors 104
4.4 Measurement of Osmotic Suction 105
4.4.1 Osmotic Tensiometers 105
4.4.2 Pore Fluid Extraction Technique 106
4.5 Measurement of Total Suction 107
4.5.1 Psychrometers 109
4.5.2 Filter Paper Method for Total Suction 110
References 114
5. STATE OF STRESS AND CONSTITUTIVE RELATIONSHIPS 119
5.1 State of Stress and Stress State Variables 119
5.2 Stress–Volume Relationships 124
5.3 Stress–Water Relationships 125
References 126
6. OEDOMETER TESTING 127
6.1 Consolidation-Swell and Constant Volume Tests 129
6.2 Correction of Oedometer Test Data 132
6.2.1 Correction for Oedometer Compressibility 133
6.2.2 Correction for Specimen Disturbance in the CV Test 137
6.2.3 Effect of the Corrections on Expansion Properties 138
6.3 Relationship Between CS and CV Swelling Pressures (the m Method) 140
6.4 Factors Influencing Oedometer Test Results 144
6.4.1 Initial Stress State Conditions 145
6.4.2 Soil Fatigue 146
6.4.3 Initial Consolidation of Sample 146
6.4.4 Time and Method of Inundation 147
6.4.5 Storage of Samples 148
6.4.6 Competency of Laboratory Personnel 149
References 149
7. WATER MIGRATION IN EXPANSIVE SOILS 152
7.1 Water Flow in Unsaturated Soils 153
7.1.1 Darcy’s Law for Unsaturated Soils 153
7.1.2 Water Mass Balance Equation 154
7.1.3 Vertical Seepage in Unsaturated Soil 155
7.1.4 Flow through Fractured Rocks and Bedding Planes 158
7.2 Depth and Degree of Wetting 162
7.2.1 Depth of Wetting 162
7.2.2 Degree of Wetting 163
7.2.3 Perched Water Tables in Layered Strata 164
7.2.4 Wetting Profiles 165
7.3 Determination of Final Water Content Profiles for Design 167
7.3.1 Hand Calculation of Final Water Contents for Design 168
7.3.2 Computer Modeling of Water Migration 170
7.4 Challenges in Water Migration Modeling for Expansive Soils 177
References 178
8. COMPUTATION OF PREDICTED HEAVE 182
8.1 Oedometer Methods 183
8.1.1 The Heave Equation 184
8.1.2 Computation of Free-Field Heave 186
8.1.3 Computation of Heave under an Applied Load 195
8.1.4 Computation of Design Heave 195
8.1.5 Discussion of Earlier Oedometer Methods Proposed to Compute Heave 201
8.1.6 Comments on the Heave Index 204
8.2 Soil Suction Methods 204
8.2.1 McKeen (1992) 205
8.2.2 Department of the Army (1983) 211
8.2.3 Hamberg and Nelson (1984) 212
8.2.4 Lytton (1994) 213
8.3 Empirical Methods 214
8.4 Progression of Heave with Time 214
8.4.1 Hyperbolic Equation 214
8.4.2 Use of Water Migration Modeling to Analyze Rate of Heave 221
8.5 Free-Field Surface Movement for Shrink–Swell Soils 222
8.6 Discussion of Heave Prediction 223
References 224
9. GENERAL CONSIDERATIONS FOR FOUNDATION AND FLOOR DESIGN 227
9.1 Risk and Life Cycle Costs 230
9.1.1 Classification of Expansion Potential 230
9.1.2 Risk Factor 234
9.2 Foundation Alternatives 243
9.3 Factors Influencing Design of Structures on Expansive Soils 243
9.3.1 Tolerable Foundation Movement 243
9.3.2 Design Life 251
9.3.3 Design Active Zone and Degree of Wetting 252
9.3.4 Site Grading 252
9.4 Remedial Measures 253
References 255
10. SOIL TREATMENT AND MOISTURE CONTROL 258
10.1 Overexcavation and Replacement 259
10.2 Prewetting Method 264
10.3 Chemical Admixtures 267
10.3.1 Lime Treatment 267
10.3.2 Cement Treatment 273
10.3.3 Fly Ash Treatment 274
10.3.4 Chemical Injection 274
10.4 Moisture Control Alternatives 275
10.4.1 Moisture Barriers 276
10.4.2 Subsurface Drains 281
10.4.3 Surface Grading and Drainage 283
10.5 Summary of Soil Treatment Methods 289
References 290
11. DESIGN METHODS FOR SHALLOW FOUNDATIONS 295
11.1 Spread Footing Foundations 295
11.1.1 Computation of Footing Heave 297
11.1.2 Spread Footing Design Examples 299
11.2 Stiffened Slab Foundations 308
11.2.1 Edge Heave and Center Heave 308
11.2.2 Differential Heave 311
11.3 Remedial Measures for Shallow Foundations 314
11.3.1 Footing Foundations 314
11.3.2 Stiffened Slab-on-Grade 317
11.3.3 Other Methods 318
References 318
12. DESIGN METHODS FOR DEEP FOUNDATIONS 320
12.1 Pier and Grade Beam Foundation 320
12.1.1 Design Methods 324
12.1.2 Load-Bearing Capacity 334
12.2 Patented Piers 335
12.2.1 Helical Piles 335
12.2.2 Micropiles 337
12.2.3 Push Piers 340
12.3 Deep Foundation Design Examples 342
12.3.1 Rigid Pier Design Example 342
12.3.2 APEX Design Example 345
12.3.3 Helical Pile Design Example 348
12.4 Remedial Measures for Deep Foundations 348
12.4.1 Pier and Grade Beam Foundation 349
12.4.2 Underpinning 349
References 350
13. FLOORS AND EXTERIOR FLATWORK 351
13.1 Slabs-on-Grade 351
13.2 Stiffened Slabs 356
13.3 Structural Floors 357
13.4 Exterior Slabs and Flatwork 358
13.5 Remediation Techniques 359
13.5.1 Structural Floor Systems 361
13.5.2 Moisture Control 361
13.5.3 Chemical Injection 361
13.5.4 Isolation of the Slab 361
13.5.5 Exterior Slabs 362
References 362
14. LATERAL PRESSURE ON EARTH RETAINING STRUCTURES 363
14.1 Computation of Lateral Pressure from Expansive Soils 363
14.2 Testing for Measuring Lateral Swelling Pressure 365
14.3 Reduction of Lateral Swelling Pressure 366
14.4 Design for Lateral Earth Pressure 367
References 370
Index 373
