Description
Book SynopsisFault analysis of highly-integrated semiconductor circuits has become an indispensable discipline in the optimization of product quality. Integrated Circuit Failure Analysis describes state-of-the-art procedures for exposing suspected failure sites in semiconductor devices. The author adopts a hands-on problem-oriented approach, founded on many years of practical experience, complemented by the explanation of basic theoretical principles. Features include: Advanced methods in device preparation and technical procedures for package inspection and semiconductor reliability. Illustration of chip isolation and step-by-step delayering of chips by wet chemical and modern plasma dry etching techniques. Particular analysis of bipolar and MOS circuits, although techniques are equally relevant to other semiconductors. Advice on the choice of suitable laboratory equipment. Numerous photographs and drawings providing guidance for checking results. Focusing on modern techniques, this practical text
Table of ContentsPurpose and Importance of Preparatory Semiconductor Analysis.
Opening the Package: Chip Insulation.
Wet Chemical Etching Procedures for Removing Layers of the ChipStructure.
Crystallographic Etching in the Silicon.
Dry Etching in the Plasma.
Microsectioning Technology, Metallography.
Outlook.
Appendices.
Index.
