VLSI Circuit Design Methodology

    Product form

    £79.16

    Includes FREE delivery

    RRP £87.95 – you save £8.79 (9%)

    Order before 4pm tomorrow for delivery by Mon 6 Jul 2026.

    A Paperback / softback by Liming Xiu

      Trusted by thousands of customers. See 2,385+ Customer Reviews

      View other formats and editions of VLSI Circuit Design Methodology by Liming Xiu

      Publisher: John Wiley & Sons Inc
      Publication Date: 18/12/2007
      ISBN13: 9780470127421, 978-0470127421
      ISBN10: 0470127422

      Description

      Book Synopsis
      This book was written to arm engineers qualified and knowledgeable in the area of VLSI circuits with the essential knowledge they need to get into this exciting field and to help those already in it achieve a higher level of proficiency. Few people truly understand how a large chip is developed, but an understanding of the whole process is necessary to appreciate the importance of each part of it and to understand the process from concept to silicon. It will teach readers how to become better engineers through a practical approach of diagnosing and attacking real-world problems.

      Table of Contents

      Foreword xi
      Richard Templeton

      Foreword xiii
      Hans Stork

      Preface xv

      Acknowledgments xvii

      CHAPTER 1 THE BIG PICTURE 1

      1. What is a chip? 1

      2. What are the requirements of a successful chip design? 3

      3. What are the challenges in today’s very deep submicron (VDSM), multimillion gate designs? 4

      4. What major process technologies are used in today’s design environment? 5

      5. What are the goals of new chip design? 8

      6. What are the major approaches of today’s very large scale integration (VLSI) circuit design practices? 9

      7. What is standard cell-based, application-specific integrated circuit (ASIC) design methodology? 11

      8. What is the system-on-chip (SoC) approach? 12

      9. What are the driving forces behind the SoC trend? 15

      10. What are the major tasks in developing a SoC chip from concept to silicon? 15

      11. What are the major costs of developing a chip? 16

      CHAPTER 2 THE BASICS OF THE CMOS PROCESS AND DEVICES 17

      12. What are the major process steps in building MOSFET transistors? 17

      13. What are the two types of MOSFET transistors? 19

      14. What are base layers and metal layers? 20

      15. What are wafers and dies? 24

      16. What is semiconductor lithography? 28

      17. What is a package? 33

      CHAPTER 3 THE CHALLENGES IN VLSI CIRCUIT DESIGN 41

      18. What is the role of functional verification in the IC design process? 41

      19. What are some of the design integrity issues? 44

      20. What is design for testability? 46

      21. Why is reducing the chip’s power consumption so important? 48

      22. What are some of the challenges in chip packaging? 49

      23. What are the advantages of design reuse? 50

      24. What is hardware/software co-design? 51

      25. Why is the clock so important? 54

      26. What is the leakage current problem? 57

      27. What is design for manufacturability? 60

      28. What is chip reliability? 62

      29. What is analog integration in the digital environment? 65

      30. What is the role of EDA tools in IC design? 67

      31. What is the role of the embedded processor in the SoC environment? 69

      CHAPTER 4 CELL-BASED ASIC DESIGN METHODOLOGY 73

      32. What are the major tasks and personnel required in a chip design project? 73

      33. What are the major steps in ASIC chip construction? 74

      34. What is the ASIC design flow? 75

      35. What are the two major aspects of ASIC design flow? 77

      36. What are the characteristics of good design flow? 80

      37. What is the role of market research in an ASIC project? 81

      38. What is the optimal solution of an ASIC project? 82

      39. What is system-level study of a project? 84

      40. What are the approaches for verifying design at the system level? 85

      41. What is register-transfer-level (RTL) system-level description? 86

      42. What are methods of verifying design at the register-transfer-level? 87

      43. What is a test bench? 88

      44. What is code coverage? 89

      45. What is functional coverage? 89

      46. What is bug rate convergence? 90

      47. What is design planning? 91

      48. What are hard macro and soft macro? 92

      49. What is hardware description language (HDL)? 92

      50. What is register-transfer-level (RTL) description of hardware? 93

      51. What is standard cell? What are the differences among standard cell, gate-array, and sea-of-gate approaches? 94

      52. What is an ASIC library? 103

      53. What is logic synthesis? 105

      54. What are the optimization targets of logic synthesis? 106

      55. What is schematic or netlist? 107

      56. What is the gate count of a design? 111

      57. What is the purpose of test insertion during logic synthesis? 111

      58. What is the most commonly used model in VLSI circuit testing? 112

      59. What are controllability and observability in a digital circuit? 114

      60. What is a testable circuit? 115

      61. What is the aim of scan insertion? 116

      62. What is fault coverage? What is defect part per million (DPPM)? 117

      63. Why is design for testability important for a product’s financial success? 119

      64. What is chip power usage analysis? 120

      65. What are the major components of CMOS power consumption? 121

      66. What is power optimization? 123

      67. What is VLSI physical design? 123

      68. What are the problems that make VLSI physical design so challenging? 124

      69. What is floorplanning? 128

      70. What is the placement process? 131

      71. What is the routing process? 133

      72. What is a power network? 135

      73. What is clock distribution? 139

      74. What are the key requirements for constructing a clock tree? 143

      75. What is the difference between time skew and length skew in a clock tree? 145

      76. What is scan chain? 149

      77. What is scan chain reordering? 151

      78. What is parasitic extraction? 152

      79. What is delay calculation? 155

      80. What is back annotation? 156

      81. What kind of signal integrity problems do place and route tools handle? 156

      82. What is cross-talk delay? 157

      83. What is cross-talk noise? 158

      84. What is IR drop? 159

      85. What are the major netlist formats for design representation? 162

      86. What is gate-level logic verification before tapeout? 162

      87. What is equivalence check? 163

      88. What is timing verification? 164

      89. What is design constraint? 165

      90. What is static timing analysis (STA)? 165

      91. What is simulation approach on timing verification? 169

      92. What is the logical-effort-based timing closure approach? 173

      93. What is physical verification? 178

      94. What are design rule check (DRC), design verification (DV), and geometry verification (GV)? 179

      95. What is schematic verification (SV) or layout versus schematic (LVS)? 181

      96. What is automatic test pattern generation (ATPG)? 182

      97. What is tapeout? 184

      98. What is yield? 184

      99. What are the qualities of a good IC implementation designer? 187

      Conclusion 189

      Acronyms 191

      Bibliography 195

      Index 199

      Recently viewed products

      © 2026 Book Curl

        • American Express
        • Apple Pay
        • Diners Club
        • Discover
        • Google Pay
        • Maestro
        • Mastercard
        • PayPal
        • Shop Pay
        • Union Pay
        • Visa

        Login

        Forgot your password?

        Don't have an account yet?
        Create account
