Description
Book SynopsisA practical guide to LTE design, test and measurement, this new edition has been updated to include the latest developments This book presents the latest details on LTE from a practical and technical perspective.
Table of ContentsChapter 1 LTE Introduction 1Moray Rumney
1.1 Introduction 1
1.2 LTE System Overview 1
1.3 The Evolution from UMTS to LTE 3
1.4 LTE/SAE Requirements 4
1.5 LTE/SAE Timeline 7
1.6 Introduction to the 3GPP LTE/SAE Specification Documents 8
1.7 References 10
Chapter 2 Air Interface Concepts 112.1 Radio Frequency Aspects 11
Moray Rumney2.2 Orthogonal Frequency Division Multiplexing 53
Moray Rumney2.3 Single-Carrier Frequency Division Multiple Access 62
Moray Rumney2.4 Multi-Antenna Operation and MIMO 67
Peter Cain2.5 References 89
Chapter 3 Physical Layer 913.1 Introduction to the Physical Layer 91
3.2 Physical Channels and Modulation 91
Mitsuru Yokoyama, Bai Ying3.3 Multiplexing and Channel Coding 111
Ryo Yonezawa3.4 Introduction to Physical Layer Signaling 128
Mark Stambaugh, Jean-Philippe Gregoire, Peter Goldsack3.5 Physical Layer Procedures 142
Peter Goldsack, Dr. Michael Leung, Dr. K. F. Tsang, CityU3.6 Physical Layer Measurements and Radio Resource Management 148
Moray Rumney3.7 Summary 157
3.8 References 157
Chapter 4 Upper Layer Signaling 1594.1 Access Stratum 159
Peter Goldsack, Sarabjit Singh, Steve Charlton, Venkata Ratnakar and Darshpreet Sabharwal4.2 Non-Access Stratum 178
Sarabjit Singh, Niranjan Das, andPeter Goldsack4.3 References 194
Chapter 5 System Architecture Evolution 195Per Kangru, JDSU; Eng Wei Koo, JDSU; Mary Jane Pahls; Sandy Fraser5.1 Requirements for an Evolved Architecture 195
5.2 Overview of the Evolved Packet System 199
5.3 Quality of Service in EPS 217
5.4 Security in the Network 221
5.5 Services 222
5.6 References 226
Chapter 6 Design and Verification Challenges 2296.1 Introduction 229
Moray Rumney6.2 Simulation and Early R&D Hardware Testing 232
Jinbiao Xu and Greg Jue6.3 Testing RFICs With DigRF Interconnects 285
Chris Van Woerkom and Roland Scherzinger6.4 Transmitter Design and Measurement Challenges 296
Ben Zarlingo, Moto Itagaki, Craig Grimley and Moray Rumney6.5 Receiver Design and Measurement Challenges 340
Randy Becker, Naoya Izuchi and Sandy Fraser6.6 Receiver Performance Testing 356
Sandy Fraser, Naoya Izuchi and Randy Becker6.7 Testing Open- and Closed-Loop Behaviors of the Physical Layer 378
Peter Cain6.8 Design and Verification Challenges of MIMO 392
Peter Cain and Greg Jue6.9 Beamforming 430
Craig Grimley6.10 SISO and MIMO Over-the-Air Testing 455
Allison Douglas and Moray Rumney6.11 Signaling Protocol Development and Testing 472
Ian Reading6.12 UE Functional Testing 480
Mike Lawton6.13 Battery Drain Testing 493
Moray Rumne and, Ed Brorein6.14 Drive Testing 499
Bob Irvine, JDSU6.15 UE Manufacturing Test 509
Jeff Dralla, Ken Horn and Moray Rumney6.16 References 526
Chapter 7 Conformance and Acceptance Testing 5297.1 Introduction to Conformance Testing 529
Moray Rumney7.2 RF Conformance Testing 531
Hiroshi Yanagawa, Gim-Seng Lau, Andrea Leonardi and Moray Rumney7.3 UE Signaling Conformance Testing 549
Pankaj Gupta, and Moray Rumney7.4 UE Certification Process (GCF and PTCRB) 555
Masatoshi Obara, Mike Lawton and Moray Rumney7.5 Operator Acceptance Testing 560
Bill McKinley7.6 References 564
Chapter 8 Looking Towards 4G: LTE-Advanced 567
Moray Rumney8.1 Summary of Release 8 567
8.2 Release 9 568
8.3 Release 10 and LTE-Advanced 573
8.4 Release 11 587
8.5 Release 12 595
8.6 References 600
List of Acronyms 601
Index 613
