Description
Book SynopsisContains the most extensive coverage of digital integrated circuits available in a single source. Provides complete qualitative descriptions of circuit operation followed by in-depth analytical analyses and spice simulations. The circuit families described in detail are transistor-transistor logic (TTL, STTL, and ASTTL), emitter-coupled logic (ECL), NMOS logic, CMOS logic, dynamic CMOS, BiCMOS structures and various GASFET technologies. In addition to detailed presentation of the basic inverter circuits for each digital logic family, complete details of other logic circuits for these families are presented.
Table of ContentsPartial table of contents:
Properties and Definitions of Digital ICS.
Diodes.
Bipolar Junction Transistors.
Diode-Transistor Logic (DTL).
Schottky Transistor-Transistor (STTL).
Other TTL Gates.
Basic Emitter-Coupled Logic (ECL).
MECL III and ECL 10K.
Other ECL Gates.
Introduction to MOS Digital Circuits.
Resistor Loaded NMOS Inverter.
Enhancement-Depletion Loaded NMOS Inverter.
NMOS Gates.
CMOS Inverter.
CMOS Tri-State Gates.
CMOS Drivers.
Dynamic CMOS.
BiCMOS.
Latches and Flip-Flops.
Semiconductor Read-Only Memories.
Direct Coupled NMESFET Logic (DCFL) Inverter.
Schottky Diode NMESFET Logic (SDFL) Inverter.
Other Gallium Arsenide Logic Family Inverters.
Gallium Arsenide NMESFET Gates.
Appendices.
Supplementary Reading.
Selected Answers.
Index.
