Description
Book SynopsisUp-to-date coverage of the analysis and applications of coplanar waveguides to microwave circuits and antennas
The unique feature of coplanar waveguides, as opposed to more conventional waveguides, is their uniplanar construction, in which all of the conductors are aligned on the same side of the substrate. This feature simplifies manufacturing and allows faster and less expensive characterization using on-wafer techniques.
Coplanar Waveguide Circuits, Components, and Systems is an engineer''s complete resource, collecting all of the available data on the subject. Rainee Simons thoroughly discusses propagation parameters for conventional coplanar waveguides and includes valuable details such as the derivation of the fundamental equations, physical explanations, and numerical examples.
Coverage also includes:
- Discontinuities and circuit elements
- Transitions to other transmission media
- Directional couplers, hybrids, and magic T
Trade Review
"A resource for engineers, collecting all available data on the subject of coplanar waveguide circuits, components, and systems." (SciTech Book News Vol. 25, No. 2 June 2001)
Table of Contents
Preface.
Introduction.
Conventional Coplanar Waveguide.
Conductor-Backed Coplanar Waveguide.
Coplanar Waveguide with Finite-Width Ground Planes.
Coplanar Waveguide Suspended Inside A Conducting Enclosure.
Coplanar Striplines.
Microshield Lines and Coupled Coplanar Waveguide.
Attenuation Characteristics of Conventional, Micromachined, and Superconducting Coplanar Waveguides.
Coplanar Waveguide Discontinuities and Circuit Elements.
Coplanar Waveguide Transitions.
Directional Couplers, Hybrids, and Magic-Ts.
Coplanar Waveguide Applications.
References.
Index.
