Description
Book SynopsisNMR Probeheads for Biophysical and Biomedical Experiments is essential reading for anyone in the field of NMR or MRI, from students to medical or biological scientists performing experiments under certain physical and/or geometrical conditions, unattainable by conventional or available probes. The material guides the reader through the most basic and comprehensive stages in accomplishing a correct probe design, from a very basic oscillating circuit to much more elaborate designs. The general principles of matching and tuning probes are presented while some typical examples are explained in detail. Preventing NMR probes from becoming radiating antennas, multiple tuning principles, and steps for evaluating and debugging a probe are all covered. For the first time, these principles are applied for both homogeneous and heterogeneous resonators. The book is accompanied by a CD that contains software utilities used to exemplify the stages of different probe designs.
Table of ContentsRelating the NMR Receiving/Transmitting Coil(s) to the Spectrometer; Matching the Probe Resonator to 50 ; Balancing the Probe Head; Quadrature Driving; Multiple Frequencies Tuning; Magnetic Field Amplitude Estimation; Homogeneous Resonators; Heterogeneous Resonators. Combination of Coils; Adjusting, Evaluating, Testing and Debugging the Probe; Useful Information; Appendices: Solving the Impedance Matching; Calculation of the Current Distribution; Calculation of the Magnetic Field Distribution; A Simple Linear Network Analysis Program.
