This groundbreaking text/lab manual introduces significant concepts in the fields of Human Machine Interface (HMI) and Programmable Logic Controllers. Hands-on, step-by-step activities provide experiences in creating various process-control applications with HMI devices and software—programming that enables an HMI system operator to interface and interact directly with the system. This book is ideal for introducing high school and college students, plus those in the professional fields of process control and automation, to the capabilities and potential of HMI.
Features
- Introduces students and those in industry to the capabilities of Human Machine Interface.
- The text and activities, while ranging from basic to more advanced, assume no prior experience working with HMI devices and software.
- Readers experiment with programming that enables an HMI system operator to interface and interact directly with the system
Table of Contents
Introduction to Human Machine Interface and Programmable Logic Controllers for Process Control. Types of HMI Displays. Rockwell Automation HMI Softwares. Panel Builder 32 & Graphic Terminal Labs: Lab 1- Basic Motor Starter; Lab 2- Analog & Digital Displays; Lab 3- Pump & Tank; Lab 4- Alarms; Lab 5- Analog Input with Math Operations; Lab 6- Security. RSView 32 Computer Based Labs: Lab 1- Basic Basic Motor Starter; Lab 2- Analog & Digital Displays; Lab 3- Pump & Tank; Lab 4- Alarms; Lab 5- Math Operations, Subprograms & Alarms; Lab 6- Security; Lab 7- TrendX Charting & Data Logging; Lab 8- Moving Animation.
