Book SynopsisTable of ContentsElectronics Fundamentals
Part I DC Circuits
Chapter 1 Quantities and Units
1-1 Scientific and Engineering Notation
1-2 Units and Metric Prefixes
1-3 Metric Unit Conversions
1-4 Measured Numbers
1-5 Electrical Safety
Chapter 2 Voltage, Current, and Resistance
2-1 Atoms
2-2 Electrical Charge
2-3 Voltage
2-4 Current
2-5 Resistance
2-6 The Electric Circuit
2-7 Basic Circuit Measurements
Application Assignment: Putting Your Knowledge to Work
Chapter 3 Ohm’s Law, Energy, and Power
3-1 Ohm’s Law
3-2 Application of Ohm’s Law
3-3 Energy and Power
3-4 Power in an Electric Circuit
3-5 The Power Rating of Resistors
3-6 Energy Conversion and Voltage Drop in a Resistance
3-7 Power Supplies
3-8 Introduction to Troubleshooting
Application Assignment: Putting Your Knowledge to Work
Chapter 4 Series Circuits
4-1 Resistors in Series
4-2 Total Series Resistance
4-3 Current in a Series Circuit
4-4 Application of Ohm’s Law
4-5 Voltage Sources in Series
4-6 Kirchhoff’s Voltage Law
4-7 Voltage Dividers
4-8 Power in Series Circuits
4-9 Voltage Measurements
4-10 Troubleshooting
Application Assignment: Putting Your Knowledge to Work
Chapter 5 Parallel Circuits
5-1 Resistors in Parallel
5-2 Total Parallel Resistance
5-3 Voltage in a Parallel Circuit
5-4 Application of Ohm’s Law
5-5 Kirchhoff’s Current Law
5-6 Current Dividers
5-7 Power in Parallel Circuits
5-8 Troubleshooting
Application Assignment: Putting Your Knowledge to Work
Chapter 6 Series-Parallel Circuits
6-1 Identifying Series-Parallel Relationships
6-2 Analysis of Series-Parallel Resistive Circuits
6-3 Voltage Dividers with Resistive Loads
6-4 Loading Effect of a Voltmeter
6-5 The Wheatstone Bridge
6-6 Thevenin’s Theorem
6-7 The Maximum Power Transfer Theorem
6-8 The Superposition Theorem
6-9 Troubleshooting
Application Assignment: Putting Your Knowledge to Work
Chapter 7 Magnetism and Electromagnetism
7-1 The Magnetic Field
7-2 Electromagnetism
7-3 Electromagnetic Devices
7-4 Magnetic Hysteresis
7-5 Electromagnetic Induction
7-6 Applications of Electromagnetic Induction
Application Assignment: Putting Your Knowledge to Work
Part II AC Circuits
Chapter 8 Introduction to Alternating Current and Voltage
8-1 The Sinusoidal Waveform
8-2 Sinusoidal Voltage Sources
8-3 Voltage and Current Values of Sine Waves
8-4 Angular Measurement of a Sine Wave
8-5 The Sine Wave Formula
8-6 Analysis of AC Circuits
8-7 Superimposed DC and AC Voltages
8-8 Nonsinusoidal Waveforms
8-9 The Oscilloscope
Application Assignment: Putting Your Knowledge to Work
Chapter 9 Capacitors
9-1 &nbs
