Description
Book SynopsisDesign of analog multipliers discusses what an analog multiplier and its related types is, how different types of analog multipliers are implemented with analog two to one multiplexers and op-amps, and how the types of analog multipliers are implemented with transistors and op-amps. Describing forty-eight analog multiplier circuits, book explains six building blocks as integrator, comparator, switch, low pass filter, peak detector and sample & hold circuit. All analog multiplier circuits presented in this book use a maximum of four operational amplifiers which will enable the readers to simulate the multipliers with minimum number of components and use for their application at low cost.
Table of Contents1 Basic Concepts and Components 2 Conventional Multipliers 3 Time Division Multipliers (TDMs): Multiplexing 4 Peak Responding Multipliers: Multiplexing 5 Time Division Multipliers (TDMs): Switching 6 Peak Responding Multipliers (PRMs): Switching 7 Pulse Position Responding Multipliers (PPRMs) 8 Peak Responding Multipliers with V/T and V/f Converters
